Elation Lighting VX4S

Features

User Friendly LED Display Controller
Powerful Front End Processor
Up to 1920 x 1200 p @60Hz Input Resolution
Multiple Video Signal Format Support
New Generation Point-By-Point Correction Technology
Cascade Multiple Units Together Via USB
Rack Mountable Aluminum Enclosure (screws not included)

Specifications

CONTROL / CONNECTIONS
(1) RJ45 LAN for IP Based Control
(4) RJ45 Outputs for up to 2.6 million Pixels of LED Control
(2) USB Type A and (2) USB Type B Ports (1 set on each side)
(1) 1/8 inch (3.5mm) Audio Input
Video Input: (1) DP / (1) HDMI / (2) VGA / (1) DVI / (2) CVBS / (1) SDI
Video Output: (1) DVI Loop / (1) DVI / (1) VGA / (1) SDI Loop
Locking IEC Power Input

SIZE / WEIGHT
Length: 19.0” (483mm)
Width: 10.8” (275mm)
Height: 1.8” (45mm)
Weight: 5.6 lbs. (2.55 kg)

ELECTRICAL
AC 100-240V – 50/60Hz – 0.65A
Max Power Consumption: 16W

INCLUDED CABLES (1 each)
DP, VGA, USB, HDMI, DVI, CAT5, Power

Specifications and documentation subject to change without notice.
