Martin PDE BreakOut Cable
The Martin PDE BreakOut Cable is a purpose-built signal distribution solution designed to work seamlessly with the Martin VDO Atomic fixture family. This cable consolidates power, DMX, and ethernet into a single connection point, then breaks out each signal type to industry-standard connectors, streamlining cable runs and reducing connection points on complex rigs.
Signal Distribution & Connectivity
The cable accepts a single PDE Hybrid Connector input carrying power, DMX, and ethernet signals, then splits them into three separate outputs: Neutrik powerCON TRUE1 TOP for AC power, Neutrik etherCON TOP for network data, and Neutrik XLR 5-pin Female TOP for DMX control. All connectors are IP65 rated and hot-plugging compatible, allowing safe connection and disconnection during live operation.
Build & Environmental Durability
Measuring 500 mm (19.7 inches) in length and weighing just 325 g (0.52 lbs.), the cable remains compact and lightweight for mobile setups and permanent installations. The black PVC housing and IP65 rating ensure reliable performance in varied studio and venue environments, with an operating temperature range of -15°C to 75°C covering most seasonal conditions.
Key Features
- Splits Power, DMX, and Ethernet from single PDE Hybrid Connector input
- AC Power output: Neutrik powerCON TRUE1 TOP (IP65)
- Ethernet output: Neutrik etherCON TOP (IP65)
- DMX output: Neutrik XLR 5-pin Female TOP (IP65)
- 500 mm (19.7 in.) cable length
- Weighs 325 g (0.52 lbs.)
- IP65 rated for outdoor use
- All connectors support hot plugging
- Black PVC housing
- Operating temperature range: -15°C to 75°C
- Compatible with Martin VDO Atomic fixture family
The Martin PDE BreakOut Cable eliminates the need for multiple adapter cables and junction boxes, delivering clean signal distribution in a single, weatherproof package.
